Westire ANSI/NEMA Socket & Bracket Kit
ACCESSORIES
Accommodates all ANSI/NEMA twist-lock sockets for wall or pole mounting a photocell
Overview
Westire’s ANSI/NEMA Mounting Bracket kit is ideal for mounting a locking type photocontroller on buildings, structures, walls or wooden poles. The mounting bracket can also be supplied as a kit which includes the NEMA socket, gasket, fastening screw, IP67 connecting cable and sealing grommet.
Longevity
Engineered and assembled in the EU, with a 15 year design life using only name brand components and high quality materials. Westire’s Mounting Brackets are renowned in the industry for their unparalleled quality and reliability.
Features & Benefits
- Ideal for surface mounting a locking type Photocell & Smart City photocells on poles, walls etc.
- Supplied as a kit which includes the ANSI C136.41 / NEMA socket, gasket, fastening screws, sealing IP 67 gland and the connecting cable.
- Connection is 3 & 7 NEMA
- Compatible with 3 pin or 7 pin NEMA/ANSI C136 sockets.
- The mounting bracket is manufactured from the same UV stabilised materials as found in our Longlife Photocell products.
Technical Specification
Socket Specification | Bracket Specification |
|||
| Dimensions | 92 mm W x 134 mm H (bracket + socket installed) | Socket Housing Material | Polycarbonate UV stabilised | |
| Warranty | 10 Year Standard | Bracket Material | Zinc Plated Steel | |
| Standards Compliance | Cable Sealing Rating | IP67 | ||
| Load Current (A) | 15 Amps | Cable Length | Up to 8 m | |
| Sealing Gasket | EDPM | Material Specification | UL94V-0 Flame Retardancy | |
| Socket Pads | 3, 5, or 7 | |||
| Socket Pads | ANSI C136-41 s | |||
| Enclosure Protection Rating | IP65 | |||
| Operating Temperature | -40° C to +80° C -40° F to +176° F | |||
