Mains Power Tap

Our mains Power Tap is a versatile method of providing mains power to outdoor devices via street lights. It delivers auxiliary power to third-party equipment through the luminaire’s ANSI/NEMA receptacle.

The Power Tap enclosure is manufactured from UV stabilised polycarbonate, providing long-life durability and it is sealed to IP65 protecting against dust and water ingress. Manufactured at our in-house facility in Ireland, EU, using only high-quality name brand components our mains Power Tap comes with a 5-year warranty as standard.

Overlay Dots

Installation Can Take Place in Three Easy to Follow Steps:

  1. Remove the photocell from the NEMA/ANSI receptacle and insert the Power Tap twist and is locked into place.
  2. Insert the removed photocell back into the Power Tap’s own NEMA/ANSI receptacle twist and it’s locked into place.
  3. Connect the Power Tap’s cable (2 meters in length as standard) and its best practice to connect an in-line RCD to the auxiliary device requiring the supply.

You can also combine our mains Power Tap with our ANSI/NEMA receptacle and bracket kit for wall or pole mounting of both the Power Tap and the photocell.

Power Tap Mains RCD Overview

Mains Street Light Power Tap for Smart Cities

A street light Power Tap is a simple and reliable way to deliver auxiliary power from street lights to 3rd party devices to support smart cities. Technologies such as wi-fi access points, CCTV cameras and traffic sensors can all ‘tap’ into the mains power supply of the existing infrastructure. It’s also a great way to introduce festive or temporary lighting without interrupting existing photocell operation.

Smart City

Features & Benefits of a Mains Power Tap

  • Ideal for the supply of temporary mains power.
  • Supports the powering of smart IoT devices utilising street lights.
  • Supplies power to festive, amenity or security lighting.
  • Features an external, easy to access fusing which protects auxiliary equipment.
  • Supplied with cable lengths of 2 meters standard, other lengths available on request.
  • Designed to meet water and dust tight rating of IP65.
  • Tamper proof.

Technical Specification

Dimensions

113 mm (H) x 83 mm (W), 4.45" (H) x 3.27" (W)

Warranty

5 years standard

Cable Length

2 meters standard

Operating Temperature

-20°C to 80°C, -4° F to 176° F

Power Tap Receptacle

Designed to BS5972 & ANSI C136.41

Connecting Pins

Designed to BS5972 & ANSI C136.10

Power Tap Enclosure Materials & Sealing

UV stabilised polycarbonate sealed to IP65

Mains Supply

105 to 480 V AC 50/60Hz

Max Load Current

10 A

Fusing

10 A optional

Download Specifications PDF

Sectors

Housing Estates

Road & Motorways

Streets

Campuses & Car Parks

Applications

  • Festive lighting
  • CCTV Cameras
  • WiFi Access Points
  • Wireless Equipment
  • Licence Plate Readers
  • Smart City IoT Devices
  • Smart City Pollution Sensors
  • Noise Sensors
  • Emergency EV Charging
  • Holiday Park Temporary Lighting
  • Town & City Street Environmental Sensors
  • Town & City Weather Stations
  • Small Cell Radios
  • Traffic & Pedestrian Flow Counters
  • Temporary Signage
  • Wildlife Monitoring

Get in Touch

Looking for easy to install ‘tap-and-play’ solutions to connect third-party devices into street lights, we have a number of Power Tap options. Complete the form and one of our team will be in touch to discuss your requirements.
